Home /Products/Industrial Control Automation/YASKAWA SPS-1.5-4000 1.5kW High-speed Spindle Motor for CNC Machine Tools

YASKAWA SPS-1.5-4000 1.5kW High-speed Spindle Motor for CNC Machine Tools

1pcs
MOQ
1250-1550$
Price
YASKAWA SPS-1.5-4000 1.5kW High-speed Spindle Motor for CNC Machine Tools
Features Gallery Product Description Chat Now
Features
Specifications
Output Type: Digital And Analog Outputs
Communicationprotocols: Modbus, Profibus, Ethernet/IP, OPC UA
Controltype: Programmable Logic Controller (PLC)
Operatingtemperature: -20°C To 60°C
Width: 22.5 Mm
Numberofinputs: 16 Digital Inputs
Compliancestandards: IEC 61131, ISO 9001
Output Points: 20
Max Switching Current: 6 A
Type: Automation System
Shockresistance: 30g, 11ms
Managementinterface: Web GUI, SNMP, CLI
Memory: 1
Operating Temperature: -20°C To 60°C
Warrantyperiod: 1 To 3 Years
Highlight:

YASKAWA 1.5kW spindle motor

,

high-speed spindle motor for CNC

,

SPS-1.5-4000 CNC spindle motor
Basic Infomation
Place of Origin: Japan
Brand Name: YASKAWA
Certification: CO
Model Number: SPS-1.5-4000
Payment & Shipping Terms
Packaging Details: pieces
Delivery Time: 5-8days
Payment Terms: T/T
Supply Ability: 96PCS 1-2weeks
Product Description
Electrical Specifications
Rated input voltage (V) Three-phase 380V AC
Rated power (kW) 1.5kW
Rated torque (N·m) 3.58N·m
Instantaneous maximum torque (N·m) 7.16N·m
Rated current (A) 3.8A
Instantaneous maximum current (A) 7.6A
Rated speed (rpm) 4000rpm
Maximum speed (rpm) 6000rpm
Mechanical Specifications
Moment of inertia (kg·m²) 0.00085kg·m²
Allowable radial load (N) 150N
Allowable axial load (N) 80N
Shaft configuration Straight shaft with keyway
Mounting method Flange-mounted
Encoder type 17-bit incremental encoder (standard)
Brake No built-in brake
Performance Specifications
Speed control range 1:1000
Speed control accuracy ±0.02%
Overload capacity 200% rated torque for 10 seconds
Environmental Specifications
Operating temperature 0 to +40 degrees Celsius
Storage temperature -20 to +70 degrees Celsius
Operating humidity 20% to 80% RH (non-condensing)
Altitude Below 1000 meters, no derating required
Protection level IP44
Insulation class F class
Safety standards CE, UL, cUL, RoHS
Cooling method Forced air cooling
Dimensions (D*L) 100mm * 210mm
Weight Approximately 6.5kg
